Indoor Fiber Optic Cables
Distribution Cable
Product Description:
Category:
Indoor Fiber Optic Cables
- 产品描述
- Features
- Application
- Specification
- Download
-
Tight buffered fiber, easy to strip;
Aramid yarn as the strength member to improve the tensile performance of the cable;
Flame retardant, environmentally friendly, corrosion resistant out sheath.
-
Indoor cable distribution;
Backbone distribution cable in building;
Multi-fiber jumper.
-
Structural Parameters
Fiber Count
Strength Member
Cable Diameter
（mm）
Weight（kg/km）
Minimum Bending Radius
（mm）
Tensile Load（N)
Crush Load (N/100mm)
Temperature Range
(℃)
Static
Dynamic
Short Term
Long Term
Short Term
Long Term
2
Aramid Yarn
4.5±0.1
19.2
45
90
400
200
1000
200
-20℃-+60℃
4
Aramid Yarn
5.0±0.1
20.5
50
100
400
200
1000
200
-20℃-+60℃
6
Aramid Yarn
5.5±0.1
28.3
55
110
660
200
1000
200
-20℃-+60℃
8
Aramid Yarn
6.0±0.1
32.9
60
120
660
200
1000
200
-20℃-+60℃
12
Aramid Yarn
6.5±0.1
36.5
65
130
660
200
1000
200
-20℃-+60℃
16
Aramid Yarn
7.0±0.1
45.2
70
140
660
200
1000
200
-20℃-+60℃
24
Aramid Yarn
8.5±0.1
67.2
85
170
1320
400
1000
200
-20℃-+60℃
36
Aramid Yarn
10.5±0.2
89.8
105
210
1320
400
1000
200
-20℃-+60℃
48
Aramid Yarn
11.5±0.5
106.9
115
230
1320
400
1000
200
-20℃-+60℃
72
Aramid Yarn
19.5±0.5
581.3
195
390
1320
400
1000
200
-20℃-+60℃
96
Aramid Yarn
22.8±0.8
728.4
228
456
1320
400
1000
200
-20℃-+60℃
144
Aramid Yarn
26.4±0.8
797.8
264
528
1320
400
1000
200
-20℃-+60℃
Optical Characteristics
Fiber Type
Attenuation（dB/km）
Overfilled Launch Bandwidth (MHz.km)
Effective Mode Bandwidth
(MHz.km)
1310nm
1550nm
850nm
1300nm
850nm
1300nm
850nm
G.652D
≤0.4
≤0.3
－
－
－
－
－
G.657A
≤0.4
≤0.3
－
－
－
－
－
OM1
－
－
≤3.0
≤1.0
≥200
≥500
OM2
－
－
≤3.0
≤1.0
≥500
≥500
OM3
－
－
≤3.0
≤1.0
≥1500
≥500
≥2000
OM4
－
－
≤3.0
≤1.0
≥3500
Standard Length
Length: 1000m/2000m, or customer standard.
