OptiTap Fiber Optical Cable

Product Description:

Toneable design : Copper element allows for toneable locationDielectric rods: Excellent crush resistanceIndoor/outdoor design:Tight Buffered cable can be placed in a riser environment and is UL listedMeets GR-20 specifications : Industry acc...

Category:

Outdoor Fiber Optic Cables

+86 18145922016

sales@fiber-mile.com

CONTACT+

产品描述
Features
Application
Specification
Download

- Toneable design : Copper element allows for toneable location
- Dielectric rods: Excellent crush resistance
- Indoor/outdoor design:Tight Buffered cable can be placed in a riser environment and is UL listed
- Meets GR-20 specifications : Industry accepted standard for OSP installations
- Cable in a cable : Eliminates splice at premises wall
- TeraFlex fiber in a flexible tight buffer cable design : Inner cable can be ped around corners and stapled with no attenuation issues
- The kind of cable is suitable for duct, aerial and buried installation.
- The kind of cable is suitable for area with lightning strike..

Items		GYFTY Fiber Optic Cable Non-metallic cable ASU cable
Fiber	Fiber type	G.652D
	Fiber count	1-24
	Color	Blue/Orange/Green/Brown/Grey/White/Red/Black/Yellow/Violet/Pink/Aqua
Loose tube	Material	PBT
	Diameter	1-12 cores:1.8 ±0.1mm;24cores:2.4 ±0.1mm
	Water-blocking material	Gel-filled
Strength member	Material	FRP
Strength member	Diameter	1-12 cores:1.0 ±0.1mm;24cores:1.5 ±0.1mm
Outer jacket	Material	MDPE
	Color	Black
	Thickness	1-12 cores:3.5 ±0.1mm;24cores:4.2 ±0.1mm
	Diameter	1-12 cores:6.5 ±0.2mm;24cores:8.5 ±0.2mm
